Danfoss
RT 107
Pressure Transmitter Pressure Switch • Electronic Control
Quick Stats
Series
RT
Type
Pressure Transmitter
Function
Pressure Sensing
Contacts
-
Reset Type
-
Pressure transmitter with 4-20mA output for electronic control systems.
Technical Specifications
Pressure Range
| Range (bar) | -1 to 10 |
| Range (psi) | -14.5 to 145 |
Electrical
| Output | 4-20mA (2-wire) |
| Power Supply | 10-30V DC |
Physical
| Connection | 1/4" SAE flare |
| Enclosure | IP65 |
| Temp Range | -40 to +85°C |
| Max Working Pressure | 17 bar |
Compatible Refrigerants
All common refrigerants
Wiring Diagram
| Terminal | Function |
|---|---|
| + | Supply voltage (+) |
| - | Signal output / Supply (-) |
Applications
- Electronic pressure monitoring
- Building management systems
- PLC control
- Data logging
Cross Reference / Alternatives
Emerson PT5
Penn P499
Manufacturer Information
Brand: Danfoss
Country: Denmark
