Danfoss
KP35
High Pressure Pressure Switch • R410A/High Pressure Systems
Quick Stats
Series
KP
Type
High Pressure
Function
High Pressure Cut-Out
Contacts
SPDT
Reset Type
Automatic or Manual
High range pressure switch for R410A and other high pressure refrigerants.
Technical Specifications
Pressure Range
| Range (bar) | 15 to 45 |
| Range (psi) | 218 to 653 |
| Differential (bar) | 3.0 to 9.0 |
Electrical
| Contact Type | SPDT |
| Contact Rating | 16A/250VAC |
Physical
| Connection | 1/4" SAE flare |
| Enclosure | IP30 |
| Max Working Pressure | 53 bar |
Compatible Refrigerants
R410A
R32
R407C
R134a
Typical Settings
| Application | Cut-Out | Differential | Cut-In |
|---|---|---|---|
| R410A | 42 bar | 6 bar | 36 bar |
Applications
- R410A split systems
- VRF systems
- High pressure refrigerant protection
Cross Reference / Alternatives
Ranco O12-4825
Penn P70MA
Manufacturer Information
Brand: Danfoss
Country: Denmark
