KP15
Dual Pressure Pressure Switch • Combined Hi/Lo Protection
Quick Stats
Series
KP
Type
Dual Pressure
Function
High & Low Pressure Cut-Out
Contacts
SPDT (each)
Reset Type
LP Auto, HP Auto or Manual
Dual pressure switch combining high and low pressure functions in one unit.
Technical Specifications
Pressure Range
| LP Range (bar) | -0.2 to 7.5 |
| HP Range (bar) | 8 to 32 |
Electrical
| Contact Type | SPDT (each) |
| Contact Rating | 16A/250VAC (each) |
Physical
| Connection | 2x 1/4" SAE flare |
| Enclosure | IP30 |
| Max Working Pressure | 17 (LP) / 35 (HP) bar |
Compatible Refrigerants
R134a
R404A
R407C
R22
R507A
Wiring Diagram
| Terminal | Function |
|---|---|
| 1 | LP Common |
| 2 | LP Normally Closed |
| 4 | LP Normally Open |
| 5 | HP Common |
| 6 | HP Normally Closed |
Applications
- Complete compressor protection
- Packaged units
- Condensing units
Cross Reference / Alternatives
Ranco O12-1502
Penn P20EA
Manufacturer Information
Brand: Danfoss
Country: Denmark
