Danfoss
KP36
Condenser Fan Control Pressure Switch • Head Pressure Control
Quick Stats
Series
KP
Type
Condenser Fan Control
Function
Condenser Fan Cycling
Contacts
SPDT
Reset Type
Automatic
Pressure switch for condenser fan cycling to maintain head pressure in low ambient.
Technical Specifications
Pressure Range
| Range (bar) | 6 to 22 |
| Range (psi) | 87 to 319 |
| Differential (bar) | 1.5 to 5.0 |
Electrical
| Contact Type | SPDT |
| Contact Rating | 16A/250VAC |
Physical
| Connection | 1/4" SAE flare |
| Max Working Pressure | 25 bar |
Compatible Refrigerants
R134a
R404A
R407C
R22
Typical Settings
| Application | Cut-Out | Differential | Cut-In |
|---|---|---|---|
| R404A Fan Cycling | 13 bar | 2 bar | 15 bar |
| R134a Fan Cycling | 8.5 bar | 1.5 bar | 10 bar |
Applications
- Condenser fan cycling
- Head pressure maintenance
- Low ambient operation
Cross Reference / Alternatives
Ranco O16-109
Penn P20BB
Manufacturer Information
Brand: Danfoss
Country: Denmark
