Tado
Tado Internet Bridge
Accessories Series • Gateway Controller
Quick Info
Type
Gateway
Application
Network Bridge
Probe Inputs
Relay Outputs
Communication
Wi-Fi 802.11 b/g/n (2.4GHz), 868MHz (to Tado devices)
Panel Size
81 x 43 x 20 mm
Required gateway connecting Tado heating devices to your home network and the Tado cloud. One Bridge supports up to 25 devices.
Technical Specifications
Display & Interface
| Display Type | LED indicators |
| Display Digits | - |
| Buttons | Reset button |
Power Supply
| Voltage | 5V DC |
| Frequency | - |
| Power Consumption | < 2W |
Sensor Inputs
| Probe Inputs | - |
| Probe Type | - |
| Temp Range | -°C |
Relay Outputs
| Relay Outputs | - |
| Relay Rating | - |
Physical
| Panel Size | 81 x 43 x 20 mm |
| Depth | - mm |
| IP Rating | - |
| Weight | 34 g |
Operating Conditions
Wiring Terminals
| Terminal | Function | Type | Wire Color |
|---|---|---|---|
| 5V DC Power | Input |
N/A
|
|
| Optional wired connection | Input |
N/A
|
Important: Always disconnect power before wiring. Verify terminal numbers with the actual controller label before connecting.
Error Codes
NO_WIFI
