Emerson/Alco
XGi-32
XGi Series • Gateway Controller
Quick Info
Type
Gateway
Application
System Integration
Probe Inputs
0
Relay Outputs
2
Communication
RS485 Modbus RTU / Ethernet / BACnet / LonWorks
Panel Size
DIN rail 6M mm
Output Functions
R1
Common Alarm
R2
Status
Protocol gateway for BMS integration
Technical Specifications
Display & Interface
| Display Type | LCD |
| Display Digits | Graphic |
| Buttons | 4 |
| LED Indicators | Power, Comm1, Comm2, Alarm |
Power Supply
| Voltage | 24V AC/DC |
| Voltage Range | 18-30V AC/DC |
| Frequency | 50/60Hz |
| Power Consumption | 5W |
Sensor Inputs
| Probe Inputs | 0 |
| Probe Type | N/A |
| Temp Range | N/A°C |
| Accuracy | ±N/A |
Relay Outputs
| Relay Outputs | 2 |
| Relay Rating | 5A/250VAC |
Physical
| Panel Size | DIN rail 6M mm |
| Depth | 60 mm |
| IP Rating | IP20 |
| Weight | 200 g |
Operating Conditions
| Operating Temp | -10 to 50°C |
| Storage Temp | -25 to 60°C |
Wiring Terminals
| Terminal | Function | Type | Wire Color |
|---|---|---|---|
| 1 | Power 24V | Input |
red
|
| 2 | Power GND | Input |
black
|
| 3 | RS485-1 A+ | Comm |
orange
|
| 4 | RS485-1 B- | Comm |
yellow
|
| 5 | RS485-2 A+ | Comm |
green
|
| 6 | RS485-2 B- | Comm |
white
|
| 7 | Ethernet RJ45 | Comm |
N/A
|
| 8-9 | Alarm Relay | Output |
gray
|
| 10-11 | Status Relay | Output |
gray
|
Important: Always disconnect power before wiring. Verify terminal numbers with the actual controller label before connecting.
Parameter Settings
| Code | Parameter | Range | Default | Description |
|---|---|---|---|---|
| NC | Node Count | 1 to 127 | 32 | Number of connected devices |
| SC | Scan Rate | 1 to 60 | 5 sec | Polling interval |
| PT | Protocol | 0=Modbus,1=BACnet,2=LonWorks | 0 | Output protocol |
| bd | Baud Rate | 9600-115200 | 19200 bps | Serial speed |
Error Codes
NC
No communication
Solution: Check RS485 wiring
TO
Timeout
Solution: Device not responding
PF
Protocol fault
Solution: Check protocol settings
Frequently Asked Questions
Up to 127 Modbus devices on RS485 network
BACnet/IP, BACnet MS/TP, LonWorks, Modbus TCP
Alternative Models (Cross Reference)
Carel PGDX
Danfoss AKM
Dixell XM670K
Manufacturer Information
Brand: Emerson/Alco
Country: USA
Parent: Copeland (Emerson Climate Technologies)
