Belimo
CQ24A-SR
CQ Series • HVAC Controller
Quick Info
Type
HVAC
Application
Changeover Valve Control
Probe Inputs
0
Relay Outputs
0
Communication
MP-Bus (option)
Panel Size
- mm
6-way valve with actuator for 2-pipe changeover applications
Technical Specifications
Display & Interface
| Display Type | None |
| Display Digits | - |
| Buttons | 0 |
Power Supply
| Voltage | 24V AC |
| Voltage Range | 20-30V AC |
| Frequency | 50/60Hz |
| Power Consumption | 5VA |
Sensor Inputs
| Probe Inputs | 0 |
| Probe Type | - |
| Temp Range | -°C |
Relay Outputs
| Relay Outputs | 0 |
| Relay Rating | - |
Physical
| Panel Size | - mm |
| Depth | - mm |
| IP Rating | IP54 |
Operating Conditions
| Operating Temp | -10 to 50°C |
Wiring Terminals
| Terminal | Function | Type | Wire Color |
|---|---|---|---|
| 24V AC | Power |
power
|
|
| AC Common | Power |
power
|
|
| Control Signal | Input |
analog
|
|
| Position Feedback | Output |
analog
|
Important: Always disconnect power before wiring. Verify terminal numbers with the actual controller label before connecting.
Parameter Settings
| Code | Parameter | Range | Default | Description |
|---|---|---|---|---|
| Mode | Operating Mode | Heat/Cool/Auto | Auto | |
| Char | Characteristic | Linear/EQ% | EQ% |
Frequently Asked Questions
Alternative Models (Cross Reference)
Siemens VXP45
Honeywell V5328A
Manufacturer Information
Brand: Belimo
Country: Switzerland
